Specifications
Please note - specifications subject to change without prior notice.
| FRAME | eFLOAT LITE II ; MAT aluminium; 29"x2.4" with fender max. WHS; 148x12 AST; intube |
| SHOCK | |
| FORK | SR Suntour X1-Boost; Air; 120 STR; 29x2.4" max WHS |
| BRAKE-F | Shimano MT-200; 2 piston |
| BRAKE-R | Shimano MT-200; 2 piston |
| ROTOR-FRONT | Shimano RT10; 180mm |
| ROTOR-REAR | Shimano RT10; 180mm |
| CHAIN | Shimano LG500 |
| CHAINGUARD | |
| CRANKSET | FSA Direct Mount Steel Chainring; 38 ATC |
| CRANK SIZE | FSA CK-220 wide E-Bike Forged Crankset; 165mm for all sizes |
| DERAILLEUR-FRONT | |
| DERAILLEUR-REAR | Shimano Cues U6000; GS |
| FREEWHEEL | Shimano Cues LG400; 11-48 ATC; 10 GER |
| PEDAL | VP VPE-891 |
| GRIP | MERIDA EXPERT EC |
| HANDLEBAR | MERIDA EXPERT; MAT aluminium; 680 WHB; 15 RHB |
| STEM | MERIDA EXPERT TK III; MAT aluminium; 31.8 DSH; |
| STEM SIZE | S/M/W-S/W-M :70mm, L/XL/W-L/W-XL :90mm |
| HEADSET | Acros ICR MERIDA INTEGRATED neck w/ Blocklock |
| HUB-F | Shimano TC500; 15x100 WHF; 32 SPH; Centerlock |
| HUB-R | Shimano TC500; 12x148 WHR; 32 SPH; Centerlock |
| AXLE-F | |
| AXLE-R | MERIDA EXPERT TR; including removeable lever, 6/4mm allen key |
| SADDLE | MERIDA EXPERT TK II; V-mount |
| SEAT CLAMP | MERIDA EXPERT |
| SEAT POST | MERIDA COMP TR IV; 34.9 DSP; 0 SSB; S/M/L/XL: 150 SPT |
| SHIFTER-F | Shimano SL -MT500-L (Need to check if SL-MT500-L is competible with LIMOTEC post) |
| SHIFTER-R | Shimano CUES U6000-10 |
| SPOKE | Black stainless |
| TIRE-F | Maxxis Rekon; 29x2.4"; wire |
| TIRE-R | Maxxis Rekon; 29x2.4"; wire |
| CARRIER | MERIDA MIK HD Carrier with Spring clip & Spanninga rear light |
| FENDER | Sunnywheel SW-FA311-70A/ SW-FA311-70E1 |
| KICKSTAND | Atranvelo ED-100-PC |
| LIGHT-FRONT | Lezyne Hekto StVZO E350 Reverse; reverse MERIDA Custom Mount |
| LIGHT-REAR | Spanninga Commuter Glow XE integrated in MERIDA MIK HD carrier |
| FRAME LOCK | Abus 4650 XL |
| DRIVE UNIT | Bosch Performance Line CX |
| DRIVE COVER | MERIDA Custom Cover for Bosch Performance Line CX eFLAOT |
| BATTERY | Bosch PowerTube 800 ; 800Wh |
| SWITCH | |
| DISPLAY | Bosch Pruion 200 |
